DASH Power

Store electrical energy wherever you need it

DASH Power Systems are containerized and fully integrated systems combining GRZ Technologies’ proprietary solid-state hydrogen storage, automotive-grade fuel cell systems, and auxiliary components. They are charged with hydrogen from any source and deliver on-demand electrical power for your application. DASH Power unlock the opportunities enabled by the hydrogen-based electricity storage. Whether it is for efficient and affordable power generation, enhanced grid management, system services, or other applications, our technology will enable you to store large quantities of electrical energy wherever you need it.

Available versions

DASH-175-900

Electrical Peak Power: 175 kW
Electrical Cont. Power: 75 kW
Storage Capacity: 45 kgH2 / 0.9 MWhe
Max Operation Time at 100% load: 12.0 h

DASH-260-1800

Electrical Peak Power: 260 kW
Electrical Cont. Power: 160 kW
Storage Capacity: 90 kgH2 / 1.8 MWhe
Max Operation Time at 100% load: 11.3 h

DASH-400-2700

Electrical Peak Power: 400 kW
Electrical Cont. Power: 240 kW
Storage Capacity: 135 kgH2 / 2.7 MWhe
Max Operation Time at 100% load: 11.3 h

DASH-500-3500

Electrical Peak Power: 500kW
Electrical Cont. Power: 320 kW
Storage Capacity: 175 kgH2 / 3.5 MWhe
Max Operation Time at 100% load: 10.9 h

DASH-500-4500

Electrical Peak Power: 500 kW
Electrical Cont. Power: 340 kW
Storage Capacity: 225 kgH2 / 4.5 MWhe
Max Operation Time at 100% load: 14.0 h

Specifications

Storage Capacity0.9 to 4.5 MWh
Nominal output Power175 – 500 kW
Electrical interface3-phase 400 V 50/60 Hz
Hydrogen supply pressure30 – 45 bar(g)
Hydrogen supply purity4.5 (> 99.995%)
Communication interfaceTCP/IP OPC UA and hardwired
External Cooling requirementsNone
Container 20ft-ISO hi-cube, C5 paint, equipped with doors, fans, ventilation, light, gas sensors, dry cooler, etc.
Footprint14.8 m² (20 ft ISO container)
Weight< 29.25 t
Ambient temperature-5 – +38 °C
Expected service life> 20 years
